HDPE Butt Fusion Fittings Manufacturers

Butt fusion is the most common fusion methods for HDPE pipe, and the HDPE butt fusion fittings are the most popular used fittings for HDPE piping systems


The main features that HDPE butt fusion fittings are:

※ Reliable jointing

The HDPE pipe & HDPE butt fusion fittings are connected by butt-fusion method of joining. The jointing shall be 100% leak-free when it is properly made, the jointing is as strong as the pipe itself and has the same life expectancy.

※ Wide ranges & specifications available

HDPE butt fusion fittings can be supplied in wide ranges & specifications, which can cover all HDPE pipes. For the big diameter HDPE pipe like dn710-1200mm, fabricated type HDPE butt fusion fittings are the only choice, while HDPE electrofusion fittings are not available for most manufacturers.

※ No coupler need, Lower costs.

When HDPE pipes are connected by butt fusion methods, no any need coupler fittings be requested. By comparison to HDPE electrofusion fittings, HDPE butt fusion fittings are much lower on prices. This greatly reduce the installation costs.

※ Good flexibility

The HDPE pipes be installed by butt fusion method are much more flexible.

※ SDR11 & SDR17 for choice

HDPE butt fusion fittings can be provided in SDR11 & SDR17 with different prices. The customers can always find a correct option according to their pipe.


To achieve the butt fusion, the HDPE butt fusion fittings’ outer diameter shall be exact same to the HDPE pipe. By using a HDPE pipe butt fusion machine to fusion both ends in a certain temperature & time, and then remove the heating plates, tightly bond together the both ends under fixed pressure till it is cool down.


SUNPLAST HDPE butt fusion fittings can be provided in a diameter dn63mm to dn1200mm. The diameter DN63-800mm can be injection moulded in SDR17/SDR13.6 & SDR11, while DN900-1200mm can be provided in FABRICATED TYPE only.

Product name

Specifications available

Pressure Ratings

configurations

HDPE Butt Fusion Fittings

(Moulded Type)

63/75/90/110/125/140/160/180/

200/225/250/280/315/355/400/

450/500/560/630/710/800

SDR17/SDR13.6/SDR11

Tee, elbow 90 degree, elbow 45 degree,reducing tee, reducer, end cap, stub flanges

HDPE Butt Fusion Fittings

(Fabricated Type)

900/1000/1200

SDR11/SDR13.6/SDR17/

SDR21/SDR26

Tee, elbow 90 degree, elbow 45 degree,reducing tee, reducer, end cap, stub flanges

Download our price list HDPE BUTT FUSION FITTINGS


hdpe pipe butt fusion fittings

SUNPLAST can provide HDPE butt fusion fittings in the most common configurations of elbow 90deg, elbow 45deg, elbow 22.5deg, Tee, Reducer, Reducing tee, flange adaptors.,etc. All HDPE butt fusion fittings are made by injection moulded technology with one-time moulding, no any jointing, this allows our fittings the great reliability when bearing high pressure use.


The HDPE butt fusion fittings are made by superior quality that is approved by PE100+ association, at the same time, it can conform to ISO4427-3/EN12201-3/AS4129 standards. The below is the technical Characteristic of SUNPLAST HDPE butt fusion fittings based on ISO4427-3 standard:

Characteristic

Requirements

Test Methods

Physical characteristics for HDPE Butt Fusion Fittings

Oxidation induction time of HDPE butt fusion fittings

(200℃)

≥20min.

ISO 11357-6:2002



Melt Flow Rate of HDPE butt fusion fittings

(5Kg,190℃,10min.)

Change of MFR by

processing±20%

ISO 1133:2005

Mechanical characteristics for HDPE butt fusion fittings

Tensile strength Of HDPE butt fusion Fittings

At 23℃

Ductile — Pass

Brittle — Fail

ISO 13953

Hydrostatic strength of HDPE butt fusion fittings

at 20℃

For PE80 Pipe

20℃, 100h, 10Mpa

No leak, No break

ISO 1167

For PE100 Pipe

20℃, 100h, 12.4Mpa

No leak, No break

Hydrostatic strength of HDPE butt fusion fittings

at 80℃

For PE80 Pipe

80℃, 165h, 4.5Mpa

No leak, No break

ISO 1167

For PE100 Pipe

80℃, 165h, 5.4Mpa

No leak, No break


Regular sizes & items of HDPE butt fusion fittings are available in stock, such as 63mm, 75mm, 90mm, 110mm, 160mm, 200mm, 250mm, 315mm.,etc.


Our regular exporting packing methods is cartons (cartons can print customer’s logo) for dia. Dn63-315mm. The HDPE butt fusion fittings larger to 315mm shall be wrapped by PP bags for each pieces.


Customer’s logo can be stamped or embossed on the HDPE butt fusion fittings.


SUNPLAST is ready to provide our best quality HDPE butt fusion fittings to all customers around the world, please contact us freely if you have any enquiry to us

For 24 hours contact details as below:

Email: [email protected] sunplastpipe.com

            [email protected]

Tel: 0086-574-87226883/87467583

Mobile/whatsApp/Wechat: 0086-15968493053/18858041865
